ALR-W400-2L2T
Entry-Level Precision Lifting.
- 400 kg rated load capacity
- Entry-level precision lifting platform
- Forward and backward movement with in-place rotation
- Optimized dimensions: 780 × 540 × 250 mm
- Maximum speed up to 2.0 m/s
Overview
The ALR-W400-2L2T is a compact latent lifting AMR engineered for precise and efficient pallet handling in confined industrial environments. With reliable navigation, accurate positioning, and robust safety systems, it enables smooth automation for modern warehouses and factories.
Features
- Electric latent lifting system
- Bidirectional movement with on-the-spot rotation
- High-precision stopping accuracy
- Laser & TOF-based obstacle avoidance
- Fast charging with 6-hour rated runtime
- Stable WiFi communication
Specifications
| Specification | Value |
|---|---|
| Basic Parameters | |
| Model | ALR-W400-2L2T |
| Type | Latent Lifting AMR |
| Rated Load | 400 kg |
| Product Dimensions (L×W×H) | 780 × 540 × 250 mm |
| Rotation Diameter | 810 mm |
| Lifting Distance | 60 mm |
| Ground Clearance | 20 mm |
| Lifting Pallet Dimensions | 728 × 480 mm |
| Lifting Method | Electric |
| Machine Weight | 110 kg |
| Touch Screen | 5-inch |
| Drive Method | Differential drive |
| Navigation | DM code, texture marker, laser |
| Packed Dimensions | 913 × 676 × 459 mm |
| Weight with Packaging | 150 kg |
| Mobility & Performance | |
| Max Speed (No Load) | 2.0 m/s |
| Speed (Rated Load) | 1.5 m/s |
| Stopping Position Accuracy (No Load) | ±10 mm |
| Stopping Angle Accuracy (No Load) | ±1° |
| Climbing Ability | 3° (5%) |
| Obstacle Crossing Height | 10 mm |
| Trench Crossing Ability | 25 mm |
| Operating Mode | Bidirectional (Forward / Reverse) + On-the-spot rotation |
| Safety & Protection | |
| Obstacle Avoidance | Laser + TOF |
| Collision Detection | Front & Rear |
| Emergency Stop Button | Front & Rear |
| Acoustic & Optical Alarm | Standard |
| Clearance Lights | Standard |
| Battery & Charging | |
| Charging Time | 1.2 hours |
| Charging Mode | Manual / Automatic |
| Rated Operating Time | 5.3 hours |
| Operating Environment | |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 5%–90% RH (non-condensing) |
| Communication Mode | WiFi |
